Connectors for Temperature Sensors
Standard connectors




S-027, Ceramic standard connector


Standard S-027 connectors with round pins are designed for thermocouples and RTD sensors. Solid construction provides reliable connection even in demanding applications

Features

  • * High quality ceramic housing resistant up to +650°C
  • * Easy connection of wires
  • * Solid construction
  • * Max cable diameter up to: Ø8 mm
  • * Wires diameter from Ø0.2 mm up to Ø2 mm
  • * Connector housing color: white
  • * Thermocouple type is designated on connector housing


Dimensions

Documents
