S-013, 3-pin miniature connector
S-013 connector plug with flat pins is designed for thermocouples and RTD sensors. Miniature connector is suitable for small diameter cables.
Third Cu pin is used as grounding, extension of sensor shielding or connection of 3-wire Pt100 RTD sensor.
Features
* High-quality housing resistant up to +220°C
* Easy connection of wires
* Solid construction
* Max cable diameter up to: Ø4.5 mm
* Wires diameter up to Ø0.6 mm
Dimensions
Documents
Data sheet S-013, Edition 2016 (PL)
Data sheet S-013, Edition 2016 (EN)
