Connectors for Temperature Sensors
Miniature connectors




S-015, High-temperature miniature connector


S-017 miniature connector with flat pins is designed for thermocouples and RTD sensors. Miniature connector is suitable for small diameter cables.

Features

  • * High-quality ceramic housing resistant up to +350°C
  • * Easy connection of wires
  • * Solid construction
  • * Max cable diameter up to: Ø4.5 mm
  • * Wires diameter up to Ø0.6 mm
  • * Connector housing color: brown
  • * Thermocouple type is designated on connector housing


Dimensions

Wymiary
Documents
