Resistance Thermometers (RTDs)
Sensors with connection cable




TOPE418, TOPE419, Cable resistance thermometer


Applications

  • * Measuring range: -50 .. +400°C (depends on cable insulation)
  • * Machinery industry
  • * Light energy industry
  • * General industrial services

Features

  • * Single or double RTD:
    Pt100, Pt500, Pt1000 according to PN-EN 60751
    Ni100, Ni1000 according to DIN 43760
    Cu50, Cu53 according to GOST 6651-94
  • * Stainless Steel AISI321 / 1.4541 or AISI316L / 1.4404, AISI316Ti / 1.4571 upon request
  • * Threaded process connection
  • * Construction type: straight or angle

Temperature range

Temperature range of the sensor depends on insulation of connection cable.
Temperature range Possible diameters of protection tube Cable insulation
-10 .. +105°C Ø5, Ø6, Ø8 mm PVC
-50 .. +180°C Ø5, Ø6, Ø8 mm silicone
-50 .. +260°C Ø3, Ø4, Ø5, Ø6, Ø8 mm teflon® PFA
-50 .. +400°C Ø5, Ø6, Ø8 mm fiberglass

Construction

Resistance thermometers TOPE424 are designed for temporary measurement and mobility. Recommended for laboratory application to dryblock temperature calibrators.

TOPE424 consists of thermometric resistor, sheathed cable mineral insulated inside, handgrip and twisted or straight connection cable version.



Insertion length, process connection, construction type, number of sensors, accuracy, cable insulation and method of connection can be selected individually for the respective application.

ATEX, IECEx, EAC Ex versions Certyfikaty ATEX, EAC Ex

Intrinsically safe designs are available for applications in hazardous areas. These models are provided with certificate for „intrinsically safe“ type of protection according to Directive 2014/34/UE (ATEX), IECEx scheme and EAC Ex TR-CU 012/2011 (Eurasian Economic Union).

Other versions


This data sheet contains only small part of our supplies program of cable resistance thermometers. Upon the customer's request, other versions can also be delivered.
